CA6200 2600W 2-Channel Digital Pro Amplifier 1U Rack
Professional Wireless Audio for Every Performance
Discover our range of high-performance wireless microphone systems, conference mics, and power amplifiers. Built with True Diversity UHF technology for crystal‑clear, dropout‑free sound on stage, in the studio, or in the meeting room. Free shipping, 3‑year warranty, and based support included with every order.
CA6200 2600W 2-Channel Digital Pro Amplifier
1300W RMS per Channel @ 4Ω | 1U Rack-Mountable | Class-D | For Stage, KTV & Conferences
Product Gallery
Click image to enlarge. Actual product may vary slightly. Resized for quick loading.
Product Overview
The CA6200 2-Channel Digital Power Amplifier is a reliable, professional-grade audio solution designed to meet the exacting demands of live stage performances, KTV bars, commercial conferences, and outdoor events. Delivering a solid 2600W RMS at 4 ohms (1300W x 2) and 1300W RMS at 8 ohms, it provides ample driving force for medium-to-large speaker systems. Featuring a flexible bridgeable mono mode, this amplifier can be quickly reconfigured for heavy-duty single-channel applications. The ultra-compact 1U rack-mountable metal chassis is built for space efficiency without compromising structural integrity. With professional XLR/RCA inputs and a dual-voltage selector (100-120V/220-240V), the CA6200 offers the versatility and global compatibility audio professionals rely on for their most important gigs and installations.
Key Features & Benefits
🔹 Dual-Channel High-Thrust Output for Heavy Loads
The CA6200 features robust power delivery, providing 1300W RMS per channel at 4 ohms (2600W total) and 650W per channel at 8 ohms. This power is enough to drive passive speakers, stage monitors, and subwoofers with headroom to spare for dynamic live performances.
🔹 Bridgeable Mono Mode for Extended Scenarios
This amplifier supports flexible bridgeable mono operation (available as an upgrade option). By combining the two channels, you can output significantly higher single-channel power, making it incredibly adaptable for different system configurations and boosting bass output for clubs and outdoor events.
🔹 Lightweight 1U Rack-Mount for Space Efficiency
Housed in a robust 1U rack-mountable black metal chassis, the CA6200 is extremely slim and lightweight. It saves significant space in standard 19-inch equipment racks, allowing you to fit more audio gear into mobile flight cases or compact server rooms.
🔹 Professional Inputs/Outputs & Dual Voltage Support
Designed with XLR and RCA inputs for versatile source connections, and durable speaker binding post outputs for secure, reliable wiring. Crucially, it supports a selectable dual power supply (100-120VAC or 220-240VAC), making it effortless to deploy in different global regions without external transformers.
🔹 Built for Professional Users and Diverse Scenarios
Specifically tailored for professional touring sound engineers, KTV & bar system integrators, and high-end audio enthusiasts. Whether it's energizing a live concert stage, powering the audio in a corporate conference room, or delivering non-stop playback in a bustling nightclub, the CA6200 delivers dependable performance day in and day out.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | CA6200 2CH Digital Amp |
| Channels | 2 Channel (Stereo / Bridged Mono) |
| Power Output RMS @ 4Ω | 2600W (1300W + 1300W) |
| Power Output RMS @ 8Ω | 1300W (650W + 650W) |
| Inputs | RCA, XLR |
| Outputs | Speaker Terminals (Binding Posts) |
| Voltage | 220-240VAC / 100-120VAC, 50/60Hz (Selectable) |
| Form Factor | 1U Rack-Mountable Metal Chassis |
| Amplifier Class | Class-D Digital |
| Indicators | Running Status LEDs (Power, Signal, Clip) |
What's in the Box
- ✅ 1× CA6200 2-Channel 1U Power Amplifier
- ✅ 1× AC Power Cord
- ✅ 1× User Manual
Ideal Applications
🛡️ Authorized Dealer Warranty: This product is brand new in original packaging, sold by MiCWL Audio Inc. as an authorized dealer. Covered by a 1-Year Manufacturer Warranty. Buy with confidence.
📩 Have Questions or Need a Custom Configuration?
If you have any questions about this power amplifier, need help with system matching, or want to discuss bulk / custom OEM orders — our team is ready to assist you.
✉️ shop@micwlaudio.com© 2026 MiCWL Audio Inc. All rights reserved.
